Fanimation
myFanimation - DC Motor (54, 60, 72 inch Blades) - MW (D1MW)
$1286.85
Call For Price
Enlarge Image
Add to Cart
ENERGY INFORMATION
at High Speed
Airflow
4998
Cubic Feet per Minute		 Electricity Rate
35
Watts
(excluded lights)		 Airflow Efficiency
145
Cubic Feet Per Minute Per Watt
Availability:
  • Manufacturer has 19 items available.
  • This Item has been Discontinued. Please verify product pricing and availability with vendor prior to submitting any orders.
Required Components:

Optional Accessory:

Dimensions:
right arrow Height: 14.70"
right arrow Width: 54.00"
Additional Details:
right arrow Finish: Matte White
right arrow Option: Damp Rated
right arrow Category: Fan-Multi
right arrow Family: myFanimation
right arrow Voltage: 120
right arrow Additional Info: 6,906 CFM on High , Compatible with most smart home devices , Fan Speed, Sleep Timer, Home Away, Fresh Air, Safe Exit and Reverse airflow features , Limited Lifetime Warranty , Multiple blade finishes and LED Light kit with vintage bulb available, sold separately , TR205 fanSync Bluetooth handheld remote with 3V CR2032 batteries included
right arrow Air Flow CFM: 4998
right arrow Air Flow Efficiency: 145
right arrow Amperage: 0.48
right arrow Blade Pitch: 14
right arrow Canopy: Diameter- 6.4 Height- 2.83
right arrow Diameter: 12.98
right arrow Down Rod Included: 4.5
right arrow Electricity Used: 35
right arrow Harmonized Codes: 8414.51.3000
right arrow Length: 54
right arrow Light Kit Included: No
right arrow Max Length: 72
right arrow Max Width: 72
right arrow Motor Fan Speed: 16
right arrow Motor RPM: 155
right arrow Motor Size: DC158 x 22
right arrow Motor Type: DC
right arrow Remote Control Included: TR205
right arrow Ship Carton Height: 11.7
right arrow Ship Carton Length: 14.80
right arrow Ship Carton Width: 14.8
right arrow Ship Weight: 21.16
right arrow Sold By: Each
right arrow Warranty: Limited Lifetime Warranty
right arrow Weight: 19.03
right arrow Airflow Efficiency Low: 435
right arrow Airflow Efficiency Medium: 248
right arrow Avg Airflow Efficiency: 189
right arrow Avg CFM Energy: 4561
right arrow Avg Energy Use Watts: 24
right arrow Avg Estimated Yearly Energy Cost: 7
right arrow Avg Estimated Yearly Energy Cost on HIGH: 10
right arrow Cap Included: No
right arrow Carton Cubic Feet: 1.4831
right arrow Cartons Per Unit: 1
right arrow Case Height: 11.7
right arrow Case Length: 14.8
right arrow Case Weight Pounds: 21.16
right arrow Case Width: 14.8
right arrow CEC Uploaded: Yes
right arrow Ceiling To Blade Edge: 13.2
right arrow Ceiling to Bottom No LK: 14.7
right arrow CFM Low: 1045
right arrow CFM Medium: 3348
right arrow Compatible Accessories: APG245BL, DR1-12MW, DR1-18MW, DR1-24MW, DR1-36MW, DR1-48MW, DR1-60MW, DR1-72MW, DR1-CPMW, SCK1-52MW
right arrow Compatible Blades: B154CY, B154DWA, B154MW, B154WA, B154WE, B160CY, B160DWA, B160MW, B160WA, B160WE, B172CY, B172DWA, B172MW, B172WA, B172WE, B254CY, B254DWA, B254MW, B254WA, B260CY, B260DWA, B260MW, B260WA, B272CY, B272DWA, B272MW, B272WA, B354CY, B354DWA, B354MW, B354WA,
right arrow Compatible Light Kits: F1MW, F2MW, F3MW, F4MW
right arrow Compatible Wall Controls: TW206
right arrow Country of Origin: China
right arrow Current Draw Low: 0.06
right arrow Current Draw Medium: 0.25
right arrow Damp Rated: Yes
right arrow DOE Classification: LSSD
right arrow DOE-FTC Uploaded: Yes
right arrow Exempt from DOE Procedure: No
right arrow Fan Energy Star: No
right arrow Included Control Type: Handheld
right arrow Leadwire: 80
right arrow Maximum Slope Degree: 19
right arrow Motor Finish Method Type: Painted
right arrow Motor Reversible: Yes
right arrow Number of Blades: 5
right arrow Product Certification: UL
right arrow Regulated Product: Yes
right arrow Reverse Switch Location: Control
right arrow RPM Low II: 50
right arrow RPM Medium IV: 108
right arrow Safety Rating: UL/cUL
right arrow Voltage Cycles: 60HZ
right arrow Watts Low: 2
right arrow Watts Medium: 14
right arrow Standard Category: Fans
right arrow Standard Subcategory: Fan Motor Without Blades
right arrow Standard Finish: White
right arrow Standard Style: Traditional
right arrow Standard Option: Damp Rated
right arrow Standard Number of Blades: 5 Blades
Vendor Item #:
D1MW
